The TAIFUN series is a turnkey test bench solution and is based on a modular drive and automation concept that offers the greatest flexibility and highest test quality.

The TAIFUN test is developed for the testing of

  • electric motors
  • powertrains and
  • combustion engines

Standard configurations:

In the course of the electrification of powertrains the electric motor is of highest importance. The use in the automotive sector requires compact designs with high power densities. High speed ranges cause enormous thermal stresses, so the robustness of the motors is a major challenge for the future.

The electrified powertrain is an important component of future sustainable mobility. The increased demands on performance and reliability require sophisticated solutions, especially in the powertrain. To optimise the development process with regard to dynamics, vibration and acoustics, our TAIFUN Powertrain programme offers a standardised, modular structure. For future and new test requirements in the powertrain, additional measurement and software solutions can be easily integrated.

Combustion engines that run on hydrogen, e-fuels or in hybrid operation will also retain their importance in powertrain technology for the future. In addition, the new Euro 7 standard stipulates that emissions must be further reduced and new pollutant limits defined. These emission-reducing measures must be applied across the entire engine map and, if necessary, also across a wide temperature field. Here, too, the TAIFUN series offers all the possibilities of the integrated and modular test bench platform.

Standard configurations for the electric motor test bench

TAIFUN for the electrical test stand

TAIFUN
210E

TAIFUN
265E

TAIFUN
378E

Nominal power

210 kW

265 kW

378 kW

Rated torque

450 Nm

510 Nm

1300 Nm

Rated speed

4490 rpm

4954 rpm

2775 rpm

Maximum speed

16000 rpm

16000 rpm

11000 rpm

Mass moment of inertia

0,297 kg m2

0,294 kg m2

1,913 kg m2

TAIFUN
147E

TAIFUN
250E

Nominal power

147 kW

250 kW

Nominal torque

226 Nm

500 Nm

Rated speed

6219 rpm

4770 rpm

Maximum speed

20000 rpm

20000 rpm

Mass moment of inertia

0,134 kg m2

0,334 kg m2

TAIFUN 210E

TAIFUN_210E_EN

TAIFUN 265E

TAIFUN_265E_EN

TAIFUN 378E

TAIFUN_378E_EN

TAIFUN 147E

TAIFUN_147E_EN

TAIFUN 250E

TAIFUN_250E_EN

Standard configurations for the e-powertrain



TAIFUN
146GS

TAIFUN
270GS

TAIFUN
400GS

Nominal power

146 kW

270 kW

400 kW

Rated torque

2620 Nm

4160 Nm

5000 Nm

Rated speed

531 rpm

615 rpm

756 rpm

Maximum speed

1500 rpm

4000 rpm

3000 rpm

Mass moment of inertia

6,029 kg m2

13,029 kg m2

5,729 kg m2

TAIFUN 270GS

TAIFUN 146GS

TAIFUN 400GS

Standard configurations for the internal combustion engine test bench

TAIFUN for the internal combustion engine test bench

TAIFUN
265

TAIFUN
350

TAIFUN
470

Nominal power

265 kW

350 kW

470 kW

Rated torque

730 Nm

1000 Nm

990 Nm

Rated speed

3452 rpm

3341 rpm

4548 rpm

Maximum speed

10000 rpm

9000 rpm

9000 rpm

Mass moment of inertia

0,65 kg m2

0,91 kg m2

0,91 kg m2

TAIFUN for the internal combustion engine test bench

TAIFUN
475L

TAIFUN
620L

TAIFUN
810L

Nominal power

475 kW

620 kW

810 kW

Rated torque

3000 Nm

4050 Nm

5130 Nm

Rated speed

1504 rpm

1458 rpm

1513 rpm

Maximum speed

4500 rpm

4000 rpm

3500 rpm

Mass moment of inertia

6,72 kg m2

14,1 kg m2

18,57 kg m2

TAIFUN 265

TAIFUN_265_EN

TAIFUN 350

TAIFUN_350_EN

TAIFUN 470

TAIFUN_470_EN

TAIFUN 475L

TAIFUN_475L_EN

TAIFUN 620L

TAIFUN_620L_EN

TAIFUN 810L

TAIFUN_810L_EN

Special solutions with the same standards are also possible on request.

More information about the TAIFUN modular test bench platform can be found in the brochure and flyer:

System overview for both test stand types

TAIFUN system overview

Test bench automation and control for all types of automotive test benches:

Basic hardware and software NUCLIO

  • Controller and licences
  • Basic test bench software

Modular expansion stages for the following applications

  • Internal combustion engine test bench
  • eTraction test bench
  • VKM / Hybrid Powertrain Test Bench FWD / RWD / AWD
  • eDrive powertrain test bench FWD / RWD/ AWD
  • Back2Back component test bench
  • eDrive Back2Back endurance test bench
OPVnuclio Software

Optional real-time modules

  • Combustion engine simulation
  • Driver and vehicle simulation
  • Drive train simulation
  • Battery simulation

All functionalities in one system

  • Test bench configuration with existing library for a wide range of test bench equipment and test runs
  • Integration of Simulink user models
  • Multi-stage limit value monitoring
  • Test creation on a work-flow basis
  • Manual / Partial / and Fully Automated Test Execution
  • Online editable visualisation
  • Effective data evaluation during shutdown
  • Flexible result storage and export functions

As an extension for this test bench platform for engine test benches, powertrain test benches are also which are then individually projected according to requirements. These are also based on proven, standardised drive technology with our ECODyn modules and the same test bench automation and control NUCLIO.
